Model |
3.2V100AH |
Single |
|
|
Casing material for single cell |
方形铝壳 |
|
|
|
Standard capacity（0.2C5A） |
100Ah |
|
|
|
Rated voltage |
25.6V |
Work voltage：3.20V |
|
|
Max Charge voltage |
29.2V |
Single Ave. charge Voltage ：3.65V
|
|
|
Cut-off voltage |
20V |
Single Ave. Discharge Voltage ：2.50V |
|
|
Standard charge current |
65A |
0.65C |
|
|
charging Time |
About 1.5h |
|
|
|
Max Continuous discharge current |
65A |
0.65C |
|
|
Peak discharge current |
70A>10S |
|
|
|
Battery dimension |
532*207*215mm |
|
|
|
Total weight（Approx.) |
19kg |
|
|
|
Impedance（Max, at 1000Hz.） |
≤ 4 0mΩ |
|
|
|
Charge method (CC/CV) |
Standard |
0℃～45℃ |
|
|
discharge |
-20℃～65℃ |
|
|
|
storage |
0℃～45℃ |
|
|
