Nominal Voltage |
25.2V |
Nominal Capacity |
200Ah (0.2C to8.4V at 25℃) |
Power |
5040Wh |
(AC) Internal Resistance |
≤150mΩ |
Cycle life |
>1200 cycles @0.2C 80%DOD |
Month self-discharge |
<3% |
Charge voltage |
29.4±0.2V |
Charge mode |
0.2C to 29.4V, then29.4V,charge current to 0.02C (CC/CV) |
Charge current |
10-100A |
Max charge current |
200A |
Charge cut-off voltage |
29.4V±0.2V |
Constant current |
10-100A |
Max constant current |
200A |
Discharge cut-off voltage |
19.6V |
Cell / Connection mode |
NCM 100 7 S 2P |
Case |
胶壳 |
Dimension(mm) |
520*267*221 |
Weight(lbs./kg.) |
35.5kg |
Terminal |
M8铜端子 |
Communication Protocol (Optional) |
RS485/CAN2.0 |
Extend (Optional) |
LED/蓝牙 |
