Model |
3.2V6AH |
Single |
|
|
Casing material for single cell |
钢壳(32700) |
|
|
|
Standard capacity（0.2C5A） |
24Ah |
|
|
|
Rated voltage |
12.8V |
Work voltage：3.20V |
|
|
Max.Charge voltage |
14.6V |
Single Ave. charge Voltage) |
|
|
Cut-off voltage |
10V |
Single Ave. Discharge Voltage：2.50V |
|
|
Standard charge current |
20A |
1C |
|
|
charging Time |
About 1h |
|
|
|
Max Continuous discharge current |
20A |
|
|
|
Peak discharge current |
50A 10S |
|
|
|
Battery dimension |
180.5*76*165mm |
|
|
|
Total weight（Approx.) |
About2.8kg |
|
|
|
Impedance（Max, at 1000Hz.） |
≤ 6 0mΩ |
|
|
|
Charge method (CC/CV) |
Standard |
0℃～45℃ |
|
|
discharge |
-20℃～65℃ |
|
|
|
storage |
0℃～45℃ |
|
|
