1. Safety: telecom base station lifepo4 battery, built-in BMS, no fire, none explosive
2. Clean and green energy, does not contain toxic material
3. Powerful
4. Prolonged life cycle, after 2000 cycles, the residual capacity exceeds 80% of its original capacity.
5. No memory effect, highly efficient charging at any time
6. Wide operating temperature: -10 ~ 55 ° C
7. Small size and light weight.
8. Low self-discharge rate: <3% monthly
9. With individual package, clear warning mark, logo. Instruction manual printed in colors
10. Max Power LiFePO4 Battery have high energy Density, Long cycle life,widely work temperature range and good safety performance, Mainly use in solar power system.wind power,and others energy storage power systems. UPS system, telecommunications system.As well as electric tools ,electric bicycles ，electric motorcycles,military equipment amd other fields.
| Model/Parameters | SZMP-LFP-72100 |
| Rated Voltage | 76.8V |
| Rated Capacity (0.2C，@25℃) | 100Ah |
| Rated Energy | 7680Wh |
| Cell & Pack | LiFePO4, Prismatic, Aluminum shell |
| Output voltage range | 60.0V~86.4V |
| Charging voltage | 84~85.2V, CC-CV |
| Cut-off voltage | 60.0V |
| Internal Resistance | ≤10mΩ |
| Max. Constant Charging current | 120A |
| Recommended charging current | <50A, best @ 20A |
| Recommended charging type | CC-CV until current <0.02C |
| Max.Constant Discharging current | 120A |
| AH Efficiency | ≥99.4% |
| Mechanical | |
| Case material | Metal |
| Dimension L*W*H（mm）& Terminal | 700*334*237, M8 |
| Weight（kg） | 80±0.5 |
| Humidity | 5%~95% relative humidity |
| Charging temperature | -10℃~+45℃ |
| Discharging temperature | -20℃~+65℃ |
| Storage temperature | -20℃~45℃ |
| Service Life | |
| Cycle life | 80%DOD>4000 times，@0.5C，25℃ |
| Design life | >10 years |
