Model |
3.2V160AH |
Single |
|
|
Casing material for single cell |
铝壳 |
|
|
|
Standard capacity（0.2C5A） |
160Ah |
|
|
|
Rated voltage |
51.2V |
Work voltage：3.20V |
|
|
Max Charge voltage |
58.4V |
Single Ave. charge Voltage ：3.65V
|
|
|
Cut-off voltage |
40V |
Single Ave. Discharge Voltage ：2.50V |
|
|
Standard charge current |
100A |
0.6C |
|
|
charging Time |
About 1.6h |
|
|
|
Max Continuous discharge current |
100A |
|
|
|
Peak discharge current |
|
|
|
|
Battery dimension |
640*439.5*225mm |
|
|
|
Total weight（Approx.) |
About73kg |
|
|
|
Impedance（Max, at 1000Hz.） |
≤ 4 0mΩ |
|
|
|
Charge method (CC/CV) |
Standard |
0℃～45℃ |
|
|
discharge |
-20℃～65℃ |
|
|
|
storage |
0℃～45℃ |
|
|
