Battery Model |
NP 4.5-12 12V4.5AH |
|||
|
Designer Floating Life |
Up to 3 Years |
|||
|
Capacity (25℃) |
20HR(0.275A,10.50V) |
10HR(0.52A,10.50V) |
1HR(2.75A,9.6V) |
27min(5.5A,9.6V) |
|
4.5AH |
4.3AH |
2.25AH |
2.025AH |
|
|
Dimensions |
Length |
Width |
Height |
Total Height |
|
90mm (3.54inch) |
70mm （2.76inch) |
101mm (3.98inch) |
107mm (4.21inch) |
|
|
Approx. Weight |
1.5Kg (3.3069 lbs) |
|||
|
Internal Resistance |
Full charged at 25℃:≤23mΩ |
|||
|
Self Discharge |
2% of capacity declined per month at (25℃) |
|||
|
Capacity Affected by Temp.(20HR) |
40℃ |
25℃ |
0℃ |
-15℃ |
|
102% |
100% |
80% |
55% |
|
|
Charge Voltage(25℃) |
Cycle use |
Float use |
||
|
14.4-15.0V (-18mV/℃), max. Current: 1.35A |
13.5-13.8V (-18mV/℃) |
|||
