24V40A

24V40A
Key Feature
Nominal Voltage :   25.6V
Nominal Capacity :   40Ah （0.2C to 10V at 25℃)
Power:    1024Wh
(AC) Internal Resistance:    ≤150mΩ
Cycle life:    >2000 cycles @0.2C 80%DOD
Month self-discharge:    <3%
Charge voltage:    29.2±0.2V

Notes:
Battery picture and specifications are for reference only, all different requirements can be supported by a customised service，please feel free to contact us for communication。
Feature
1. Safety: telecom base station lifepo4 battery, built-in BMS, no fire, none explosive
2. Clean and green energy, does not contain toxic material
3. Powerful
4. Prolonged life cycle, after 2000 cycles, the residual capacity exceeds 80% of its original capacity.
5. No memory effect, highly efficient charging at any time
6. Wide operating temperature: -10 ~ 55 ° C
7. Small size and light weight.
8. Low self-discharge rate: <3% monthly
9. With individual package, clear warning mark, logo. Instruction manual printed in colors
Specification
Nominal Voltage 25.6V
Nominal Capacity 40Ah （0.2C to 10V at 25℃)
Power 1024Wh
(AC) Internal Resistance ≤150mΩ
Cycle life >2000 cycles @0.2C 80%DOD
Month self-discharge <3%
Charge voltage 29.2±0.2V
Charge mode 0.2C to29.2V, then29.2V,charge current to 0.02C (CC/CV)
Charge current 10-20A
Max charge current 40A
Charge cut-off voltage 29.2V±0.2V
Constant current 10-20A
Max constant current 40A
Discharge cut-off voltage 20V
Cell / Connection mode LF26650 8S10P
Case 胶壳
Dimension(mm) 256*165*210
Weight(lbs./kg.) 9.5kg
Terminal M8铜端子
Communication Protocol (Optional) RS485/CAN2.0
Extend (Optional) LED/蓝牙
