12V7A

12V7A
Key Feature
Nominal Voltage 11.1V
Nominal Capacity 7Ah (0.2C to8.4V at 25℃)
Power 77.7Wh
(AC) Internal Resistance ≤100mΩ
Cycle life >500 cycles @0.2C 80%DOD
Month self-discharge <3%
Charge voltage 12.6±0.2V
Charge mode 0.2C to 12.6V, then12.6V,charge current to 0.02C (CC/CV)
Charge current 2A
Max charge current 5A
Charge cut-off voltage 12.6V±0.2V
Constant current 7A
Max constant current 10A
Discharge cut-off voltage 8.4V
Cell / Connection mode NCM 18650 3 S 3 P
Case 胶壳
Dimension(mm) 151*65*94
Weight(lbs./kg.) 0.75kg
Terminal T2
Communication Protocol (Optional)
Extend (Optional)
Nominal Voltage 11.1V
Nominal Capacity 7Ah (0.2C to8.4V at 25℃)
Power 77.7Wh
(AC) Internal Resistance ≤100mΩ
Cycle life >500 cycles @0.2C 80%DOD
Month self-discharge <3%
Charge voltage 12.6±0.2V
Charge mode 0.2C to 12.6V, then12.6V,charge current to 0.02C (CC/CV)
Charge current 2A
Max charge current 5A
Charge cut-off voltage 12.6V±0.2V
Constant current 7A
Max constant current 10A
Discharge cut-off voltage 8.4V
Cell / Connection mode NCM 18650 3 S 3 P
Case 胶壳
Dimension(mm) 151*65*94
Weight(lbs./kg.) 0.75kg
Terminal T2
Communication Protocol (Optional)
Extend (Optional)
