Nominal Voltage |
60V |
Nominal Capacity |
20Ah (0.2C to45V at 25℃) |
Power |
1200Wh |
(AC) Internal Resistance |
≤300mΩ |
Cycle life |
>500 cycles @0.2C 80%DOD |
Month self-discharge |
<3% |
Charge voltage |
67.2±0.2V |
Charge mode |
0.2C to 67.2V, then67.2V,charge current to 0.02C (CC/CV) |
Charge current |
5-10A |
Max charge current |
20A |
Charge cut-off voltage |
67.2V±0.2V |
Constant current |
5-15A |
Max constant current |
20A |
Discharge cut-off voltage |
45V |
Cell / Connection mode |
NCM 18650 16 S 8 P |
Case |
胶壳 |
Dimension(mm) |
185*155*220 |
Weight(lbs./kg.) |
10.5kg |
Terminal |
M4铜端子 |
Communication Protocol (Optional) |
RS485*2/CAN 2.0 |
Extend (Optional) |
LED Power display |
