Nominal Voltage |
48V(50.4) |
Nominal Capacity |
30Ah (0.2C to 40V at 25℃) |
Power |
1440Wh |
(AC) Internal Resistance |
≤300mΩ |
Cycle life |
>1000 cycles @0.2C 80%DOD |
Month self-discharge |
<3% |
Charge voltage |
54.75±0.2V |
Charge mode |
0.2C to 54.75V, then54.75V,charge current to 0.02C (CC/CV) |
Charge current |
10A |
Max charge current |
20A |
Charge cut-off voltage |
56.4V±0.2V |
Constant current |
10.0A |
Max constant current |
20A |
Discharge cut-off voltage |
40V |
Cell / Connection mode |
NCM 1850 13(14) S 12 P |
Case |
metal |
Dimension(mm) |
W442(482)*D400* H 89mm ±2(2U) |
Weight(lbs./kg.) |
20.0kg |
Terminal |
35A through terminal M4 |
Communication Protocol (Optional) |
RS485*2/RS232/Dry contact*2 |
Extend (Optional) |
MAX String*15 LED Power display |
