48v 60ah li ion

48v 60ah li ion
Key Feature

Features and advantage:
1. Safety: scooter battery, built-in BMS, no fire, none explosive
2. Clean and green energy, does not contain toxic material
3. Powerful: 3C download speed cell, 30A BMS
4. Prolonged life cycle, after 2000 cycles, the residual capacity exceeds 80% of its original capacity.
5. No memory effect, highly efficient charging at any time
6. Wide operating temperature: -10 ~ 55 ° C
7. Small size and light weight.
8. Low self-discharge rate: <3% monthly
9. With individual package, clear warning mark, logo. Instruction manual printed in colors

Specification:

Nominal Voltage 48V
Nominal Capacity 60Ah (0.2C to 36V at 25℃)
Power 2880Wh
(AC) Internal Resistance ≤280mΩ
Cycle life >800 cycles @0.2C 80%DOD
Month self-discharge <3%
Charge voltage 54.6±0.2V
Charge mode 0.2C to 54.6V, then 54.6V,charge current to 0.02C (CC/CV)
Charge current 10-60A
Max charge current 60A
Charge cut-off voltage 54.6V±0.2V
Constant current  10-60A
Max constant current 60A
Discharge cut-off voltage 36V
Cell / Connection mode NCM 13S24P
Case 铁壳
Dimension(mm) 定制
Weight(lbs./kg.) 25.5kg
Terminal  其他
Communication Protocol (Optional) RS485/CAN2.0
Extend (Optional) LED/蓝牙
